Body Type
C-SUV
Exterior Dimensions:
Length: 4640 mm
Width: 1865 mm
Height: 1665 mm
Wheelbase
2755 mm
Ground Clearance
181 mm
Kerb Weight
1683-1801 kg
Gross Vehicle Weight
2270 kg
Minimum Turning Radius
5.9 ± 0.2 m
Number of Doors
5
Seating Capacity
5 persons
Number of Seating Rows
2 rows
Trunk Capacity
Min: 582 L
Max: 1903 L
Fuel Type
Petrol

Engine

Emission Standard:
Euro 5
Displacement (cc):
1598
Max Power (HP) / rpm:
178/5500 rpm
Max Torque N-m / rpm:
265/1500-4500 rpm
Engine Type:
Smartstream G1.6 T-GDi HEV
Cylinders:
In-Line 4-Cylinder
Compression Ratio:
10.5:1
Fuel System:
GDI (Gasoline Direct Injection)
Intake System:
TIS
Fuel Tank Capacity (l):
52

Electric Motor

Motor Type:
Permanent Magnet Synchronous Motor (PMSM)
Max. Power (kW):
47.7
Max. Torque (Nm):
264

Engine + Electric Motor

Max. Power (kW):
173
Max Power (HP):
232
Max. Torque (Nm):
367

Battery

Battery Type:
Lithium ion
Voltage:
270 Volt
Battery System Capacity:
1.49 kWh
Battery Power Output:
64 kW

Drive Type and Transmission

Drive:
FWD
Transmission:
6-Speed AT
Drive Mode Select:
(Eco, Sport, My Drive)

My Drive Mode

Powertrain:
(Eco, Sport, Smart, Baby)
Steering:
(Normal, Sport)

Manual Shift Mode

Paddle Shifters:
Yes
TGS Knob:
Column Type – Shift by wire

Wheel & Tyre

Wheel Type:
Alloy Wheel
Wheel Size:
18 in
Tyre Size:
235/60 R18

Spare Wheel

Wheel Type: Temporary space saver (17 inch)

Suspension

Front: MacPherson strut type
Rear: Multi-link

Lighting

Front:
Head Lamp: Yes
Daytime Running Lamp: Yes
Headlight Delay: Yes
Rear
Rear Combination Lamp: Yes
High Mount Stop Lamp: Yes
License Plate: Yes
Rear Fog Lamp: Yes

Front Radiator Grille

Dark Chrome Coated

Bumper

Front: 2 tone
Rear: 2 tone
Finish: Body Color

Side Mirror

Electrically Adjustable: Yes
Electrically Retractable: Yes
Reverse Linked Mirrors with Turn Signal: Yes
Roof Rails: Yes
Antenna: Yes
Rear Garnish
Yes
Rear Reflectors
Yes
Spoiler
Yes
Door Scuff
Alloy
Skid Plate
Silver Painted

Steering

Material: 3 Spoke – Leather
Power Steering: Yes
Heated: Yes
Adjustment: Manual Tilt & Telescopic

Front Seat

Headrest: Up/Down (D+P)
Seat Height Adjuster: Yes (D+P)
Power Seat: Yes (D+P) 8-way powered
Lumbar Support: Driver 2-way
Ventilated Seat: Yes (D+P)
Heated Seat: Yes (D+P)
Centre Console Box: Floating Type
Memory Seat: Yes
Seat Back Pocket: Yes (D+P)

Rear Seat

Headrest: Up/Down (LH/RH/CTR)
Armrest with Cup Holder: Yes
Rear Seat Reclining: 60:40 Folding
Rear USB Charging: 2 C-Type Ports

Instrument Cluster

Cluster Type: INTEGRATED DISPLAY 12.3″ TFT LCD (CLU) + 12.3″ TFT LCD + RHEOSTAT
Head-up Display: Yes (12″ color display)

Lighting & Sensors

Auto Light Control: Yes
Parking Sensor: Forward / Side / Reverse
Blind Spot Detection (BSD)/ Lane Watch: Yes
Smart Cruise Control: Yes (w/ Stop & Go)

Steering & Controls

Steering Wheel Switches: Yes (Audio + MID + Voice Control + Vehicle Distance + Smart Cruise Control + Lane Keep Assist + Favorites)
Paddle Shifter: Yes
Trip Computer: Yes
Seat Belt Warning: Yes
Wireless Charger: Yes (w/ 2 Animations)
Multi-Purpose Tray: Yes
After Blow: Yes

Battery & Charging

Battery Charger: Front + Rear + Luggage (12V / 180W)

Audio & Connectivity

Android Auto/ Apple CarPlay: Yes (Wireless)
AM/FM Radio: Yes
MP3: Yes
Screen: INTEGRATED DISPLAY 12.3″ TFT LCD (CLU)
Floating Screen: Yes
USB: Yes
Bluetooth: Yes (w/ Voice Recognition)

Cameras & Parking

Rear View Camera: Yes (w/ Dynamic Parking Guidelines)
360 Camera: Yes
Front View Camera: Yes

Audio System

Number of Speakers: 6

Climate & Comfort

Air Conditioner Controller: 6.6 inch (Dual Zone Climate Control)
Auto Defogger: Yes
Rear AC Ventilation: Yes
Rain-sensing Wipers: Yes
Rear Wiper: Yes

Safety Features

Fingerprint (AVN Authentication + Engine Start): Yes
Keyless Entry: Smart Key
Burglar Alarm: Yes
Smart Entry + Push Start: Yes
Remote Engine Start: Yes
Anti-Lock Braking System (ABS): Yes
Electronic Brake-Force Distribution (EBD): Yes
Brake Assist (BA): Yes
Down-Hill Brake Control (DBC): Yes
Emergency Stop Signal (ESS): Yes
Multi Collision Brake (MCB): Yes
Trailer Stability Assist (TSA): Yes
Electronic Stability Control (ESC): Yes
Hill-Start Assist Control (HAC): Yes
Vehicle Stability Control (VSC): Yes
Traction Control System (TC/TCS): Yes

Airbags

Driver: Yes
Passenger: Yes
Front Side: Yes
Curtain: Yes

Parking Brake

Type: Electric
Auto Brake Hold: Yes
Electronic Parking Brake (EPB): Yes

Door Locking

Central Door Locking: Yes
Speed Sensing Door Lock: Yes
Child Safety Lock: Yes

Blind-Spot Collision-Avoidance Assist (BCA): Yes
Blind-Spot View Monitor (BVM): Yes

Driver Attention Warning (DAW)

Leading Vehicle Departure Alert: Yes

Forward Collision-Avoidance Assist (FCA 1.5)

Car / Powered two-wheeler / Pedestrian / Cyclist detection: Yes
Direct Oncoming function (FCA – DO): Yes
Junction Turning function (FCA – JT): Yes
High Beam Assist (HBA): Yes (IFS w/ Speed Options)
Manual Speed Limit Assist (MSLA): Yes
Lane Following Assist (LFA): Yes
Lane Keeping Assist – Line/Road-Edge (LKA-L/R): Yes
Parking Collision-Avoidance Assist – Reverse (PCA-R): Yes
Rear Cross-Traffic Collision-Avoidance Assist (RCCA): Yes
Crosswind Stability Control (CSC): Yes
Rear Occupant Alert (ROA): Yes
Safe Exit Assist (SEA): Yes
Smart Cruise Control with Stop & Go (SCC w/ S&G): Yes
Emergency Stop Signal (ESS): Yes

Parking Distance Warning – Forward/Side/Reverse

Dynamic guidelines & contour guidance: Yes

Surround View Monitor (SVM) Camera

3D Surround View function: Yes
Front view, rear view, side view: Yes
Top-down view w/ car wash entering mode: Yes
Front/Rear wide view function – w/ image view on command: Yes
Steering wheel with Haptic Feedback: Yes

Body Type
C-SUV
Exterior Dimensions:
Length: 4640 mm
Width: 1865 mm
Height: 1665 mm
Wheelbase
2755 mm
Ground Clearance
181 mm
Kerb Weight
1683-1801 kg
Gross Vehicle Weight
2270 kg
Minimum Turning Radius
5.9 ± 0.2 m
Number of Doors
5
Seating Capacity
5 persons
Number of Seating Rows
2 rows
Trunk Capacity
Min: 582 L
Max: 1903 L
Fuel Type
Petrol

Engine

Emission Standard: Euro 5
Displacement (cc): 1598
Max Power (HP) / rpm: 178/5500 rpm
Max Torque N-m / rpm: 265/1500-4500 rpm
Engine Type: Smartstream G1.6 T-GDi HEV
Cylinders: In-Line 4-Cylinder
Compression Ratio: 10.5:1
Fuel System: GDI (Gasoline Direct Injection)
Intake System: TIS
Fuel Tank Capacity (l): 52

Electric Motor

Motor Type: Permanent Magnet Synchronous Motor (PMSM)
Max. Power (kW): 47.7
Max. Torque (Nm): 264

Engine + Electric Motor

Max. Power (kW): 173
Max Power (HP): 232
Max. Torque (Nm): 367

Battery

Battery Type: Lithium ion
Voltage: 270 Volt
Battery System Capacity: 1.49 kWh
Battery Power Output: 64 kW

Drive Type and Transmission

Drive: FWD
Transmission: 6-Speed AT
Drive Mode Select: (Eco, Sport, My Drive)

My Drive Mode

Powertrain: (Eco, Sport, Smart, Baby)
Steering: (Normal, Sport)

Manual Shift Mode

Paddle Shifters: Yes
TGS Knob: Column Type – Shift by wire

Wheel & Tyre

Wheel Type: Alloy Wheel
Wheel Size: 18 in
Tyre Size: 235/60 R18

Spare Wheel

Wheel Type: Temporary space saver (17 inch)

Suspension

Front: MacPherson strut type
Rear: Multi-link

Lighting

Front:
Head Lamp: Yes
Daytime Running Lamp: Yes
Headlight Delay: Yes

Rear
Rear Combination Lamp: Yes
High Mount Stop Lamp: Yes
License Plate: Yes
Rear Fog Lamp: Yes

Front Radiator Grille

Front Radiator Grille: Dark Chrome Coated

Bumper

Front: 2 tone
Rear: 2 tone
Finish: Body Color

Side Mirror

Electrically Adjustable: Yes
Electrically Retractable: Yes
Roof Rails: Yes
Antenna: Yes

Rear Garnish

Rear Garnish: Yes

Rear Reflectors

Rear Reflectors: Yes

Spoiler

Spoiler: Yes

Door Scuff

Door Scuff: Alloy

Skid Plate

Skid Plate: Silver Painted

Steering

Material: 3 Spoke – Polyurethane
Power Steering: Yes
Adjustment: Manual Tilt & Telescopic

Front Seat

Headrest: Up/Down (D+P)
Seat Height Adjuster: Yes (D+P)
Power Seat: Driver only 8-way powered
Lumbar Support: Driver 2-way
Centre Console Box: Floating Type
Seat Back Pocket: Yes (D+P)

Rear Seat

Headrest: Up/Down (LH/RH/CTR)
Armrest with Cup Holder: Yes
Rear Seat Reclining: 60:40 Folding
Rear USB Charging: 2 C-Type Ports

Instrument Cluster

Cluster Type: INTEGRATED DISPLAY 12.3″ TFT LCD (CLU) + 12.3″ TFT LCD + RHEOSTAT

Lighting & Sensors

Auto Light Control: Yes
Parking Sensor: Forward / Side / Reverse
Blind Spot Detection (BSD)/ Lane Watch: Yes
Smart Cruise Control: Yes (w/ Stop & Go)

Steering & Controls

Steering Wheel Switches: Yes (Audio + MID + Voice Control + Vehicle Distance + Smart Cruise Control + Lane Keep Assist + Favorites)
Paddle Shifter: Yes
Trip Computer: Yes
Seat Belt Warning: Yes
Wireless Charger: Yes (w/ 2 Animations)
Multi-Purpose Tray: Yes

Battery & Charging

Battery Charger: Front + Rear + Luggage (12V / 180W)

Audio & Connectivity

Android Auto/ Apple CarPlay: Yes (Wireless)
AM/FM Radio: Yes
MP3: Yes
Screen: INTEGRATED DISPLAY 12.3″ TFT LCD (CLU)
Floating Screen: Yes
USB: Yes
Bluetooth: Yes (w/ Voice Recognition)

Cameras & Parking

Rear View Camera: Yes (w/ Dynamic Parking Guidelines)
360 Camera: Yes
Front View Camera: Yes

Audio System

Number of Speakers: 6

Climate & Comfort

Air Conditioner Controller: 6.6 inch (Dual Zone Climate Control)
Auto Defogger: Yes
Rear AC Ventilation: Yes
Rain-sensing Wipers: Yes
Rear Wiper: Yes

Safety Features

Keyless Entry: Smart Key
Burglar Alarm: Yes
Smart Entry + Push Start: Yes
Remote Engine Start: Yes
Anti-Lock Braking System (ABS): Yes
Electronic Brake-Force Distribution (EBD): Yes
Brake Assist (BA): Yes
Down-Hill Brake Control (DBC): Yes
Emergency Stop Signal (ESS): Yes
Multi Collision Brake (MCB): Yes
Trailer Stability Assist (TSA): Yes
Electronic Stability Control (ESC): Yes
Hill-Start Assist Control (HAC): Yes
Vehicle Stability Control (VSC): Yes
Traction Control System (TC/TCS): Yes

Airbags

Driver: Yes
Passenger: Yes
Front Side: Yes
Curtain: Yes

Parking Brake

Type: Electric
Auto Brake Hold: Yes
Electronic Parking Brake (EPB): Yes

Door Locking

Central Door Locking: Yes
Speed Sensing Door Lock: Yes
Child Safety Lock: Yes
